Key Performance Factors
Modern MTB Design
Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models
Off-Road Control
New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.
Light and Durable
All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.
Specifications:
|
Frame |
ALUXX-Grade aluminium, disc |
|
Shock |
N/A |
|
Fork |
SR Suntour XCE 28, coil spring, QR, steel steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (29), L: 100mm travel (29) XL: 100mm travel (29) |
|
Brakes |
Tektro TKD143, hydraulic, Tektro rotors [F]180mm, [R]160mm |
|
Shifters |
Shimano Acera, 2x8 |
|
Front Derailleur |
Shimano Acera |
|
Rear Derailleur |
Shimano Acera |
|
Cassette |
Shimano HG31, 11x34 |
|
Crankset |
Shimano FC-M315, 22/36 XS: 170mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29) |
|
Rims |
Giant GX03V 29 or 27.5, alloy, double wall |
|
Hubs |
Alloy, sealed |
|
Tyres |
Maxxis Ikon 27.5" or 29x2.2", wire bead |
|
Seatpost |
Giant Sport, 30.9mm |
