SuperSix EVO Spares - Gen3 2020 - 2022
Head Tube (Upper-Lower) - 44-54 cm: 1-1/8 In - 1-1/4 In, 56-62 cm: 1-1/8 In - 1-3/8 In
Headset - 44-54 cm: IS42 Top IS47 Bottom 45/45, 56-62 cm: IS42 Top IS49 Bottom 45/45
Bottom Bracket: Type/Width - PF30A / 73 mm
Front Derailleur - Brazed-On
Seat Post: Dia./Binder - 27 KNØT / Internal Wedge
Min. Seat Post Insert - 65 mm
Max. Seat Post Insert - 44cm-140 mm, 48 cm - 179 mm, 51-62 cm (measure, see Owner's Manual Supplement)
Tire Size x Max. Width - 700c x 30 mm (measured)
Fork Maximum Turning Angle - +/- 55°
Brakes: Mount Type / Min/Max Rotor Dia. - DISC: RR: Flat Mount 140mm/160mm, FT: Flat Mount 140mm/160mm RIM: Direct Mount
Axles: Type/Length - DISC: RR: Speed Release TA Double Lead / 142x12mmx1.0P/165 mm FT: Speed Release TA Double Lead / 100x12mmx1.0P / 119 mm
Max. Weight Limit: Total (Rider+All Equipment) - 129kg
